china highway road guardrail beam post hydraulic press sheet pile driver for sale

FOB Reference Price:Get Latest Price
$100.00 - $10,000.00 / Set | 1 Set/Sets china highway road guardrail beam post hydraulic press sheet (Min. Order)
Shipping:
Support Sea freight
Contact Supplier
Loading...
Report Suspicious Activity
Overview
Quick Details
Piling Speed(m/min):
50
Efficiency:
High Efficiency
Condition:
New
Place of Origin:
China
Brand Name:
Hengwang
Model Number:
HWS-PD23
Weight:
3.5-4T
Certification:
CE/SGS
Dimension(L*W*H):
10500*2500*3200mm
Name:
china highway road guardrail beam post hydraulic press sheet pile
Application:
Pile Drilling
Type:
Hydrualic
Product Name:
china highway road guardrail beam post hydraulic press sheet pile
Drill diameter:
600-1200mm
Item:
Hydraulic Pile Driver Machine
Usage:
Guard Beam Post Install Machine
Color:
Customer's Requirement
hydraulic system pressure:
20Mpa
Drilling depth:
1700mm
After-sales Service Provided:
Overseas third-party support available
Supply Ability
Supply Ability:
1000 Set/Sets per Month china highway road guardrail beam post hydraulic press sheet
Packaging & Delivery
Packaging Details
wooden case
Port
qingdao/dalian/shanghai/guangzhou/shenzhen
Lead Time :
Within 10days
Product Description

china highway road guardrail beam post hydraulic press sheet pile driver for sale

SPECIFICATIONS FOR HWS-PD23 PILE DRIVER
No.
Specifications
Unit
HW23D
1
Hydraulic hammer model
230
2
Drill rod diameter
mm
68
3
Engineer power
kw
31
4
Hydraulic system pressure
mpa
16-20
5
The hydraulic system flow rate
ml/r
63-80
6
Nitrogen gas pressure range
Mpa
1±0.1
7
Hydraulic hammer impact frequency
bpm
500-900
8
Hydraulic hammer work flow
l/min
40-70
9
Working pressure of hydraulic hammer
Mpa
 9-11
10
Working stroke of hydraulic hammer
mm
450-2800
11
Piling efficiency
mm/min
2100
12
Net weight
kg
about 2000
13
Steel post diameter
mm
90mm-500mm
14
Maximum ramming depth
mm
2000
15
Maximum post length
mm
2600
16
Drilling diameter
mm
120,150,160,180,200
17
Drilling depth
mm
1700
18
Maximum traction speed
km/h
≤30
19
Traveling Speed
km/h
8-12
20
Hydraulic tank volume
L
80
21
Dimension(L*W*H)
mm
2600*2250*2500(folded)*3700

china highway road guardrail beam post hydraulic press sheet pile driver for sale

Pile driver :
The hydraulic pile driver is a kind of multifunctional highway guardrail pile construction machinery, with different configuration it can accomplish many functions, such as piling, pile extracting, and drilling on the stable layer of road before piling.
Advantages:
1 Systems are simple; while individual units are robust, repairs to nearly any component can be made by any mechanic.
2 Parts for repairs are readily available.
3 Interchangeablity of parts is supported by all models.
4 Similarities to other machines currently in use by customers ensure that further training in the usage of these tools is unnecessary.
5 Supplying power and fuel to these system is very feasible at construction sites.

china highway road guardrail beam post hydraulic press sheet pile driver for sale

Detailed Information
FAQ

Contact: Ms. Jessica Shi                                  Email: Jessica at hengwangjx.com

Contact Us

Ms. Jessica Shi

Email: Jessica at hengwangjx.com

Mobile Phone/Whatsapp/Wechat/Skype:

+86 17701820907

china highway road guardrail beam post hydraulic press sheet pile driver for sale
