small water well drilling rigs for sale / portable downhole drill / air-controlled rig

FOB Reference Price:Get Latest Price
$2,980.00 - $3,980.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
HWS-HQZ
Power(W):
3KW
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Warranty:
1 year
After-sales Service Provided:
Online support, Field installation, commissioning and training, No overseas service provided
Place of Origin:
China
Brand Name:
Hengwang
Usage:
Coal
Voltage:
220V/380V
Weight:
150kg
Certification:
ISO
Type:
Core Drilling Rig
Power Type:
Gasoline
Dimension(L*W*H):
1524*500x300mm
Name:
small water well drilling rigs for sale / portable downhole drill
Application:
Water Wells
Drilling depth:
10-15m
Model:
HWS-HQZ
Color:
Customized
Rotary speed (r/min):
112
Gas consumption (m/min):
3.5-4.5
Cylinder diameter (mm):
90
Drill pipe (mm):
42
Supply Ability
Supply Ability:
1000 Set/Sets per Month small water well drilling rigs for sale / portable downhole dril
Packaging & Delivery
Packaging Details
wooden case
Port
shanghai qingdao dalian shenzhen ningbo
Product Description

small water well drilling rigs for sale / portable downhole drill / air-controlled rig

Application

HQZ type DTH drilling rig is mainly used for open-pit mine blasting hole chisel, it can also be used for construction, water conservancy, power engineering, highway, rail and military engineering and other outdoor drilling operations. It is one of the mainly perforation equipment in small and medium-sized open-pit mine.
HQZ type DTH drill in under 3000m altitude, temperature of 35degree celsius to 40 degree celsius - climate conditions all can use. Usually in 12 to 15m on the steps of driling and 60 75 90 degree celsius within the scope of the 150mm diameter inclined or vertical hole.

small water well drilling rigs for sale / portable downhole drill / air-controlled rig

SPECIFICATION FOR HWS-HQZ SERIES DTH DRILLING RIG
Model
HWS-HQZ10
HWS-HQZ15
HWS-HQZ20
HWS-HQZ25
Borehole  diameter(mm)
50-80
50-90
65-150
110-150
Drilling depth(m)
10-15
10-20
20-25
20-25
Rotary speed (r/min)
112
100
90
60
Gas consumption (m/min)
3.5-4.5
4-7
4-6
6-8
Cylinder diameter (mm)
90
120
150
170
Drill pipe (mm)
42
30
50-60
50-60
Electric motor (kw)
3
4
4
5.5
Overall dimensions(mm)
1524
1734
2400
1714
Weight(kg)
148
175
224
250

small water well drilling rigs for sale / portable downhole drill / air-controlled rig

Main Features

HQZ series engineering drilling machine is a kind of submersible electric electric rotary drilling rig, it is the ideal of bored piles into holes . It can make several groups into drill combination drilling used in underground continuous wall and shaft anti-seepage curtain engineering construction, etc. For silt , clay and gravel layer and weathered shale formation drilling. Widely used in civil ,traffic, water conservancy, electricity, ports and other projects of foundation construction.

small water well drilling rigs for sale / portable downhole drill / air-controlled rig

Our Company
Certificate
Successful cases
Advantages & Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Payment & Delivery
FAQ
Contact Us

Ms. Jessica Shi

Email: Jessica at hengwangjx.com

Mobile Phone/Whatsapp/Wechat/Skype:

+86 17701820907
